SF-106-8 Cyber
Network Controller

The ultimate industrial cyber network controller — 9 independent real-time hardware firewalls, AES-256-GCM-16 IPSec, health monitoring, and intelligent routing. All in one SOFTLESS appliance.

P4S · SF-106-8

One Device,
Endless Roles

Commuter · Router · Firewall · Cybersecurity · Cipher/Decipher

9 unique real-time hardware firewalls (1 per port), AES-256-GCM-16 encryption, native DDoS protection, health monitoring with anomaly reporting, and low-latency routing — all enforced in programmable silicon with zero software dependency.

9 Real-Time FWs 18 Gbps Total DIN Rail
Book a DemoDownload DatasheetRequest a Quote →
P4S SF-106-8 Network Controller — 8-port + management hardware firewall appliance
LIVE — SF-106-8 · 9 INDEPENDENT FIREWALLS

9 Real-Time FPGA Firewalls
1 Per Port — All Independent

The SF-106-8 runs 9 completely independent hardware firewalls simultaneously — each with 64 configurable rules, anti-DDoS, and AES-256 IPSec. 18 Gbps total throughput. Zero shared processing.

9 FIREWALLS ACTIVE — ALL PORTS MONITORED
0
Total Blocked
0.0
Gbps Live
100%
Block Rate
SF-106-8 — 9×RJ45 Port Matrix
0
4
1
5
2
6
3
7
8
USB-C · PSU
FPGA · 9×FIREWALL · 18Gbps
Live Threat Intercepts
Health Monitor — Anomaly Detection
CPU / FPGA Load
12%
Throughput Live
0.0 Gbps
Temperature
42°C / 85°C max
PSU Redundancy
● BOTH OK
Monitoring anomalies → CISO dashboard...
— SF-106-8 System Log — 9 Independent FPGA Firewalls —
18 Gbps capacity · 9×64 firewall rules loaded · DIN-Rail mounted
9 PORTS · 18 Gbps · REDUNDANT PSU
18
Gbps Capacity
9
Independent FW
64
Rules / Port
10W
Max Consumption
100%
Detection Rate
Technical Specifications

Hardware
Specs

Performance
Total Speed (9 ports FD)18 Gbps
Routing Latency (VPN+FW)3μs – 25μs
IPSec Speed (per port)1 Gbps AES-256-GCM-16
Max VPN Tunnels (per port)32
Firewall
Firewall Count9 (1 per port)
Rules per Port64
Hardware
Dimensions165×100×65 mm
Weight780 g
Power Supply+12V to +36V DC (Redundant)
Max Consumption10 W
Operating Temp−40°C to +85°C
Connectivity
Copper Interfaces9× RJ45 1000BaseT
Console1× USB-C
Power Supply Ports2 (Redundant)
Capabilities

What It
Does

9 Real-Time Firewalls
1 independent real-time hardware firewall per port — ultra-low latency, 64 rules per port.
AES-256 Integrity
AES-256-GCM-16 encryption. Data flow monitoring and analysis. IPSec integrity. Store & Forward.
DDoS Protection
Total protection against DoS and DDoS. Native processing in-traffic, before OS layer.
Health Monitoring
Detection, characterization, timestamping, and transmission of anomalies to CISO and AI.
Low-Latency Routing
64-byte frame <3μs · 512-byte <10μs · 1518-byte <25μs. gPTP sync ±10ns/hop.
Designed for Industries
−40°C to +85°C. DIN rail. Redundant PSU. Network or USB-C configuration.
Product References
SF-106-8-WPA
FirewallIPSecAnti-DDoSWPA3IKeV2
SF-106-8-IKEv2
FirewallIPSecAnti-DDoSWPA3IKeV2
